Miscellaneous
Appendix A Miscellaneous
Basic Standalone Operations
Card Read / Door Lock Operation
1. Present a card to a reader.
2. The reader sends the card number to a reader input on the panel.
3. The panel searches its database and:
If it is a valid card, then energizes the door relay associated with the particular
reader input. The card is valid when it is in the card database on the panel and the
current time and date conforms to the time zone associated with the card.
If it is not a valid card, the door relay remains locked.
Door Egress / Door Lock / Door Status Operation
1. Activate the door egress input.
2. The panel energizes the door relay associated with the particular door egress input
for a default time of 10 seconds.
3. If the door status goes from close to open and to close again during the 10 second
door open period, the door relay will be immediately de-energized.
IP-AK2 Panel Defaults
Reader Ports
The panel accepts a Wiegand serial data packet from the card reader. If the card is in
the database, the associated relay is activated. If the card is not in the database, the
relay state is unchanged.
The followings are the default reader ports to relay associations:
52
