Table A-1 Default Reader Ports
Reader Number Controls...
1 Relay 1 (Output 1)
2 Relay 2 (Output 2)
Reader Tamper Inputs
The card readers have a Tamper signal wired to the IP-AK2 panel. This is a two-state
input configured as a Normally Closed contact.
The followings are the default Reader Tamper Inputs to Panel Input associations:
Table A-2 Default Reader Tamper Inputs
Tamper LED Reports as...
Tamper 1 Input 7
Tamper 2 Input 8
Door Egress Inputs
The panel has a Request-To-Exit (Egress) input for each door. The default condition is a
two-state input configured as Normally Closed contact. When the egress input is active,
the associated output relay will be active.
The followings are the default egress input associations:
Table A-3 Default Door Egress Inputs
Egress input Controls relay... Panel input Reports as...
1 1 SUP1 Input 1
2 2 SUP3 Input 3
Door Status Inputs
The panel has a Door Status input for each door. The default condition is a two-state
input configured as a Normally Closed contact.
The following are the default door status input associations:
Table A-4 Default Door Status Inputs
Door Status input Panel input Reports as…
1 SUP2 Input 2
2 SUP4 Input 4
53
