Section 8 – Automation Communication Formats
8–21
Table 8–24: MX8000/685 System Messages
Printer Message 685 Automation Output
MX8000 INITIATED MESSAGES
LC Line Fault Event
LINE XXXX XXXX 7 (5 = normal,
1 new fault, 3 = line restore, 6 =
previously reported)
LC Line Fault Restore Event
LINE XXXX XXXX 7 (5 = normal,
1 new fault, 3 = line restore, 6 =
previously reported)
Main Computer Trouble RCVA 1555 5555 7
Main Computer Trouble Restore RCVA 3555 5555 7
Bkup Printer Off Line
Bkup Printer Paper Out
RCVA 5155 5555 7
Bkup Printer Restore RCVA 5355 5555 7
Bkup Computer Trouble RCVA 5515 5555 7
Bkup Computer Restore RCVA 5535 5555 7
Main Printer Off Line
Main Printer Paper Out
RCVA 5551 5555 7
Main Printer Restore RCVA 5553 5555 7
AC Trouble RCVA 5555 1555 7
AC Trouble Restore RCVA 5555 3555 7
DC Input Low
Battery Low
RCVA 5555 5155 7
DC Input Low Restore
Battery Low Restore
RCVA 5555 5355 7
Message Queue Warning
Message Queue Full (See Important
Note below)
RCVA 5555 5551 7
Message Queue Warning Restore
Message Queue Full Restore
RCVA 5555 5553 7
No Data Received
0 Length Blk
No ACK
Time Out
Illegal Specifier
Undefined Event
Unsupported Event
Unsupported Fmt
Possible Incomplete Call
Event Unsupported By Automation
Corrupted Data
Communication Error, Panel
Requested Re-send
RCVB 5555 5155 7
OPERATOR INITIATED MESSAGES
System Power Up RCVB 1555 5555 7
System Date Changed User
System Time Changed User
Time Adjusted For DST
RCVB 5555 5515 7
IMPORTANT NOTE: A "Message Queue Full" system message indicates
that the MX8000 call event buffer is full and the MX8000 receiver has gone
into a "Stop Answering Mode". This has occurred because either the printer
or automation system has failed and the MX8000 began logging events
internally (eventually filling up its internal buffer). No more calls will be
accepted until the MX8000 can free up part of its event buffer to either
the printer and/or automation system (depending upon how the system
has been configured).
