MX8000 Installation and Operation Guide
8–36
8.10.3.3 Condition Codes
Condition codes are a one-digit character that indicates the nature of the call from a control panel to the
receiver.
Table 8–44 lists the different condition codes and their descriptions:
Table 8–44: Condition Codes and Descriptions
Condition Code Description
A Alarm
B Bypass
C Closing Report
E Exit Fault
F Force Arm
G Burglary (non-ITI panels only)
H AC Restore (non-ITI panels only)
I Improper Security Code
J Trouble
L Low battery
M Medical/Auxiliary Emergency
N Fire Emergency
O Opening Report
P Power Failure (non-ITI panels only)
Q Police Emergency
R Restoral
S Supervisory
T Tamper
U Status Report (non-ITI panels only)
X Cancel
Z Phone Test
c Key Access Closing Report
o Key Access Opening Report
8.10.4 Test Record
A test record is sent when the panel date/time is updated.
The following is an example of a test record:
<"|["><"T"><"|IA1"><"|D970514"><"|T145056"><"|V042097"><"|L6.1"><"|]">
<Cksum/Ctrl><$0D>
Table 8–45 lists the information fields contained in a test record and their descriptions:
Table 8–45: Test Record Information Fields and Descriptions
Character Description Acceptable Values
I System identifier. A unit ID (always an A) and the
receiver ID digit. See 5.4.4.2 to set receiver ID.
"A" followed by 0-9.
D Date Current date in yymmdd format
yy = year, mm = month, dd = day.
T Time Current time in hhmmss format
hh = hours, mm = minutes, ss =
seconds.
V Software version In date format.
L ITIComp revision level. Two digits separated by a decimal
point.
