Section 8 – Automation Communication Formats
8–35
Table 8–42: Information Field Identifiers (cont’d)
Field Identifier Description Acceptable Values
V Panel type and revision. One panel type code byte followed
by a 4-digit revision number.
See Table 8–43.
G Group and attribute information. Contact ITI for group and attribute
information.
D Date of report. In mmdd format, where mm =
month, and dd = day.
T Time of report In hhmm format, where hh = hour,
and mm = minutes.
N Reference number. 0001-9999. See also Section 4.6.3.
Z Zone number. One to four alphanumeric
characters.
U User number. See Table 8–38 for acceptable
values.
K Dealer key numbers. For Commander 2000
only.
Values from 00-99.
S CPU sub-unit number Values from 0-9
C Condition code indicating the nature of the
reported message. See Table 8–28.
See Table 8–28for condition code
values.
8.10.3.2 Panel Type Characters
The following table lists the characters used for panel types and which panel they refer to:
Table 8–43: Panel Type Characters
Character Panel Type
Character Panel Type
0 Unknown type a 3/1
3 SX-III or SX-IVA e 3/1 extended
4 SX-IVB i 4/1
5 SX-V m 4/2
9 FonSafe r Radionics BFSK
A Commander s SIA DSC
B SX-V Special t Contact ID
C Magnetic card reader v ADEMCO TouchTone
D Euro Commander w Acron TouchTone
E Security Pro 4000 x Westec TouchTone
K HaborGard y ADEMCO DTMF 4/2
M UltraGard z ADEMCO DTMF 4/1
N Network Security # ADEMCO High Speed (SIA D1)
P Pin Point $ FSK 0
R RF Commander % FSK 1
S Commander 2000 or LifeGard & FSK 2
T CareTaker + ( FBII 4/3/1
V Protector
Z Nutone
