MX8000 Installation and Operation Guide
5–8
Table 5–4: Display Options and Descriptions (cont’d)
Display Menu
Items
Choices Default Comments
Attempts No See Section 5.4.2.5 for step-by-step instructions.
CPU Time No
CPU Type No
Panel Rev No
ITI (Edit Options)
Arming Level No
FSK1 English
BFSK Code
If “English” is selected then the printer and VFD output for calls of
these formats will be text descriptions. If “Code” is selected then
the printer and VFD output for calls of these formats will be the
Code and Zone numbers. See Section 5.4.2.6 for step-by-step
instructions.
SIA English If “English” is selected, the printer and VFD output will be text. If
“Code” is selected then the printer and VFD will display the SIA
codes followed by zone or other information. See Section 5.4.2.6
for step-by- step instructions.
CID Code This option only affects the ADEMCO 8000 automation protocol
output. If “English” is selected each event will be sent to the
automation as two SIA events; the first with the two digit Group
number and the second with the three digit ID number. If “Code” is
selected, each event is sent as eleven digits; two digits Message
type, one-digit Event Qualifier, three-digit Event Code, two-digit
Group Number, and three-digit ID number. See Section 5.4.2.6 for
step-by-step instructions.
PULSE 0 .. 9 If “0 .. 9” is selected hexadecimal digits B through F are forced to
0 as in the way the SK9000 receiver does it, or if “0 .. F” is
selected digits are sent as is.
SK9000 Packed Each data packet to the automation contains a single (unpacked)
or multiple (packed) events.
ACRON Zero Defines leading character in a 3-digit account number as a zero or
space.
FMT (Edit Format
Options)
HISPEED SIA Printer output will be in SIA format if “SIA” is selected or in a raw
data high speed format if “Hispeed” is selected.
Yes VFD will display the last acknowledged event instead of the
date/time display in the auto mode. In manual mode the display
will show the oldest unacknowledged event.
Hold Last Event
No
✔
Off
25%
✔
50%
75%
Bright
Max
Set the brightness of the Normal Operating Mode Display screen.
All other screens will be displayed at Maximum.
See Section 5.4.2.8 for step-by-step instructions.
5.4.2.1 How to Change Language Display
1. Enter program mode. (See Section 5.1.)
2. Press
1
for general options.
3. Press
2
for display options.
4. Press
until the display flashes on the language format field.
5. Press the
or button until the display flashes on the desired setting.
Note: Only English format is available at this time.
6. Press
ENTER
MENU
.
