Honeywell XENON 1902 User Manual

CHAPTER
14
Xenon/Granit User Guide 305
PRODUCT SPECIFICATIONS
Xenon 1900/1900h Corded Scanner Product
Specifications
Parameter Specification
Mechanical
Height 6.3 inches (160mm)
Length 4.1 inches (104.1mm)
Width 2.8 inches (71.1mm)
Weight 5.2 ounces (147.42g)
Electrical
Voltage Requirements 4 - 5.5 VDC at input connector
Current Draw @5VDC
B&W
Color
ScanningStandby
470mA, 2.35W90mA, .45W
490mA, 2.45W90mA, .45W
Power Supply Noise Rejection Maximum 100mV peak to peak, 10 to 100 kHz
Illumination LED:
Peak Wavelength 624nm + 18nm (red LED)
IEC 62471: “Exempt Risk Group”
442nm, 552nm (white LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength LED 624nm +
18nm (red LED)
520nm +
18nm (green LED)
IEC 62471: “Exempt Risk Group”
Optical Power Laser <1mW
Environmental
Temperature Ranges:
Operating +32F to +122F (0C to 50C)
Storage -40F to +158F (-40C to 70C)

Honeywell XENON 1902 Specifications

General

Operating frequency	2400 - 2500 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
Battery life	14 h
Charging time	4.5 h
Input voltage	5 V
Battery capacity	1800 mAh
Power source type	Battery
Number of reads per charge	50000
Power consumption (standby)	0.5 W
Shockproof	Yes
Certification	CE, UL
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	214 g
Base weight	179 g
Base dimensions	132 x 102 x 81 mm
