Honeywell XENON 1902 User Manual

308 Xenon/Granit User Guide
Xenon 1902g-BF Scanner Product Specifications
Parameter Specification
Mechanical
Height 6.3 inches (160mm)
Length 4.1 inches (104.1mm)
Width 2.8 inches (71.1mm)
Weight 6.9 ounces (195g)
Electrical
Illumination LED:
Peak Wavelength 624nm + 18nm (red LED)
IEC 62471: “Exempt Risk Group”
442nm, 552nm (white LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser 650nm
IEC 60825-1: “Class 2”
Peak Wavelength LED 624nm + 18nm (red LED)
520nm + 18nm (green LED)
IEC 62471: “Exempt Risk Group”
Optical Power Laser <1mW
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range 33 ft. (10 m) typical
Data Rate Up to 1 MBps
Environmental
Temperature Ranges:
Operating 32 F to +122 F (0 C to 50 C)
Storage -40F to +158F (-40C to 70C)
Humidity Up to 95% non-condensing
Mechanical Drop Operational after 50 drops from 3.3 feet
(1 m) to concrete
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Sensitivity Up to 15kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP41
Image Size 838 x 640 pixels
Scan Performance
Skew Angle +65°
Pitch Angle +
45°

Honeywell XENON 1902 Specifications

General

Operating frequency	2400 - 2500 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
Battery life	14 h
Charging time	4.5 h
Input voltage	5 V
Battery capacity	1800 mAh
Power source type	Battery
Number of reads per charge	50000
Power consumption (standby)	0.5 W
Shockproof	Yes
Certification	CE, UL
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	214 g
Base weight	179 g
Base dimensions	132 x 102 x 81 mm
