Xenon/Granit User Guide 51
labeling, manifesting, and shipping of spent batteries. Contact the Product Service
Department (page xvii) for recycling or disposal information. Since you may find
that your cost of returning the batteries significant, it may be more cost effective to
locate a local recycle/disposal company.
Beeper and LED Sequences and Meaning
The scanner contains LEDs on the rear of the unit that indicate linking status,
decoding state, and battery condition. The base has LEDs on the top of the unit
that indicate its power up, communication, and battery charge condition. The red
LED = error; green LED = success of any type. Scanners and the CCB01-010BT
base have audible indicators as well: 1 razz or error tone = error; 2 beeps = menu
change; 1 beep = all other successes.
The table below lists the indication and cause of the LED indication, beeps, and
vibrations for the scanner.
Scanner LED Sequences and Meaning
Base/Access Point LED Sequences and Meaning
The base contains a red LED and the Access Point has a blue LED that indicate the
status of the unit and verifies its communication with the host system. The base
also has a green LED that indicates scanner battery charge condition.
LED Indication
Beeper
Indication
Vibrate
Indication
Cause
Normal
Operation
Red Flash None None Battery low
Green Flash 1 beep None Successful communication or
linking
Red, blinking Razz or error tone None Failed communication
Menu Operation
Green Flash 2 beeps 2 vibrations Successful menu change
Red, blinking Razz or error tone 1 long vibration Unsuccessful menu change
Red or Blue LED - Host Communication
Red or Blue LED Communication Condition
Off USB suspend
On continuously Power on, system idle
Short blinks in multiple pulses. Occurs while transferring data to/
from the RF module or the Host port.
Receiving data
