Xenon/Granit User Guide 317
CCB02-100BT/CCB05-100BT Industrial
Charge Base Product Specifications
Parameter Specification
Mechanical
Height 2.6 in. (66mm)
Length 9.8 in. (248.9mm)
Width 4.05 in. (102.9cm)
Weight 10.05 oz. (285g)
Electrical
Voltage: 4.5 to 5.5 volts
Current Draw:
Host Terminal Port 500mA
Aux Power Port 1A
Charge Time 5 hours
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range 330 ft. (100m) typical
Data Rate Up to 1 MBps
Environmental
Temperature Ranges:
Operating -4 F to +122 F (-20 C to +50 C)
Battery Charge 41 F to +104 F (5 C to +40 C)
Storage without battery -40 F to +158 F (-40 C to +70 C)
Humidity Up to 95% non-condensing
Mechanical Drop Operational after 50 drops from 3.94 feet
(1.2m) to concrete
Vibration Complies with MIL-STD-810G, Method 514.6,
Annex C
ESD Sensitivity Up to 20kV direct air
Up to 8 kV indirect coupling plane
