APPENDIX
A
Xenon/Granit User Guide 339
REFERENCE CHARTS
Symbology Charts
Note: “m” represents the AIM modifier character. Refer to International Technical
Specification, Symbology Identifiers, for AIM modifier character details.
Prefix/Suffix entries for specific symbologies override the universal (All Symbologies,
99) entry.
Refer to Data Edit beginning on page 161 and Data Format beginning on page 167
for information about using Code ID and AIM ID.
Linear Symbologies
AIM Honeywell
Symbology ID
Possible modifiers
(m)
ID Hex
All Symbologies 99
Codabar ]Fm 0-1 a 61
Code 11 ]H3 h 68
Code 128 ]Cm 0, 1, 2, 4 j 6A
Code 32 Pharmaceutical (PARAF) ]X0 < 3C
Code 39 (supports Full ASCII mode) ]Am 0, 1, 3, 4, 5, 7 b 62
TCIF Linked Code 39 (TLC39)
]L2 T 54
Code 93 and 93i ]Gm 0-9, A-Z,
a-m
i69
EAN ]Em 0, 1, 3, 4 d 64
EAN-13 (including Bookland EAN)
]E0 d 64
EAN-13 with Add-On
]E3 d 64
EAN-13 with Extended Coupon Code
]E3 d 64
EAN-8
]E4 D 44

Honeywell XENON 1902 Specifications

General

Operating frequency	2400 - 2500 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
Battery life	14 h
Charging time	4.5 h
Input voltage	5 V
Battery capacity	1800 mAh
Power source type	Battery
Number of reads per charge	50000
Power consumption (standby)	0.5 W
Shockproof	Yes
Certification	CE, UL
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	214 g
Base weight	179 g
Base dimensions	132 x 102 x 81 mm
