478
I-Node or Link is init D-Node or Link is to be deleted
P-Neighbor is parent A-Node is in candidate list
C-Neighbor is child H-Nexthop changed
N-Link is a new path V-Link is involved
Area: 0.0.0.0 Shortest Path Tree
>SPFNode[0]
AdvID : 1.1.1.1 LsID : 0.0.0.0
NodeType : Router Distance : 1
NodeFlag : S R
Nexthop count: 1
-->NbrID : 1.1.1.1 NbrIntID : 21
Interface : Vlan2 NhFlag : Valid
Nexthop : FE80::20C:29FF:FED7:F308
RefCount : 4
SPFLink count: 1
-->AdvID : 1.1.1.1 LsID : 0.0.0.0
IntID : 232 NbrIntID : 465
NbrID : 2.2.2.2 LinkType : RT2RT
LinkCost : 1 LinkNewCost: 1
LinkFlag : C NexthopCnt : 0
ParentLink count: 1
-->AdvID : 1.1.1.1 LsID : 0.0.0.0
IntID : 215 NbrIntID : 466
NbrID : 2.2.2.2 LinkType : RT2RT
LinkCost : 1 LinkNewCost: 1
LinkFlag : P NexthopCnt : 0
Table 127 Command output
Field Descri
tion
SPFNode SPF node.
AdvID ID of the advertising router.
LsID Link state ID.
NodeType Node type.
Distance Cost to the root node.
NodeFlag Node flag.
Nexthop count Number of next hops.
NbrID Neighbor router ID.
NbrIntID Neighbor interface ID.
Interface Output interface.
NhFlag Next hop flag: valid or invalid.
Nexthop Next hop.
RefCount Reference count (routes that reference the next hop).
