Figure 64 Connecting the Battery Cable
3. Remove CPU 0.
See “Removing a Processor” (page 116).
4. If this is the first BBWC battery to ever have been installed in the server blade:
a. NOTE: If the bottom of the battery or top of the battery holder are dirty or oily, clean
their surfaces with a 50–50 mixture of Isopropyl alcohol and water before applying the
stickers.
Remove the protector from the sticky side of one of the plastic Dual Lock hook and loop
stickers.
Figure 65 Removing the Protector from the Sticker
b. Place the sticker on the bottom of the BBWC battery (not over the open area).
Removing and Replacing the Low Profile Battery Backed Write Cache (BBWC) Battery 133
