Chapter 4
Removing and Replacing Components
Removing and Replacing the DVD I/O Board
104
Removing and Replacing the DVD I/O Board
The DVD I/O board is located under a metal cover that is directly under DVD location at the front left of the
chassis.
WARNING Ensure that the server is powered down and all power sources have been
disconnected from the server prior to removing or replacing a DVD I/O board.
Voltages are present at various locations within the server whenever an ac power
source is connected. This voltage is present even when the main power switch is in
the off position.
Failure to observe this warning could result in personal injury or damage to
equipment.
CAUTION Failure to properly complete the steps in this procedure results in erratic server behavior or
server failure. For assistance with this procedure contact your local HP Authorized Service
Provider.
Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD
safety precautions could result in damage to the server.
Removing the DVD I/O Board
To remove the DVD I/O board, follow these steps:
Step 1. If rack mounted, slide the HP server out from the rack until it stops. See “Extending the Server
from the Rack” on page 39.
Step 2. Remove the front bezel. See “Removing the Front Bezel” on page 41.
Step 3. Remove the front cover. See “Removing the Front Cover” on page 42.
Step 4. Remove the top cover. See “Removing the Top Cover” on page 43.
Step 5. Remove the memory extender board. See “Removing the Memory Extender Board” on page 44.
Step 6. Remove the processor extender board. See “Removing the Processor Extender Board” on page 52.
