Chapter 4
Removing and Replacing Components
Removing and Replacing the DVD Drive
102
Removing and Replacing the DVD Drive
These procedures show how to remove and replace the DVD drive. The DVD drive is located on the front of
the HP server.
WARNING Ensure that the server is powered down and all power sources have been
disconnected from the server prior to removing or replacing a DVD drive.
Voltages are present at various locations within the server whenever an ac power
source is connected. This voltage is present even when the main power switch is in
the off position.
Failure to observe this warning could result in personal injury or damage to
equipment.
CAUTION Failure to properly complete the steps in this procedure will result in erratic server behavior or
server failure. For assistance with this procedure contact your local HP Authorized Service
Provider.
Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD
safety precautions could result in damage to the server.
Removing the DVD Drive
To remove a DVD drive, follow these steps:
Step 1. Grasp the front of the DVD drive and squeeze in on the locking tab to release the drive.
Step 2. Remove the front bezel. See “Removing the Front Bezel” on page 41.
