HP Integrity rx4640 User's & Service Guide

Chapter 4
Removing and Replacing Components
Removing and Replacing the Processor Extender Board
52
Removing and Replacing the Processor Extender Board
The processor extender board is located directly under the memory extender board. The processor extender
board can hold between one and four processors.
WARNING Ensure that the server is powered down and all power sources have been
disconnected from the server prior to removing or replacing the processor extender
board.
Voltages are present at various locations within the server whenever an ac power
source is connected. This voltage is present even when the main power switch is in
the off position.
Failure to observe this warning could result in personal injury or damage to
equipment.
CAUTION Failure to properly complete the steps in this procedure will result in erratic server behavior or
server failure. For assistance with this procedure contact your local HP Authorized Service
Provider.
Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD
safety precautions could result in damage to the server.
Removing the Processor Extender Board
To remove the processor extender board, follow these steps:
Step 1. If rack mounted, slide the HP server out from the rack until it stops. See “Extending the Server
from the Rack” on page 39.
NOTE If desired, the processor extender board may be removed without removing the HP
server from the rack.
Step 2. Remove the front bezel. See “Removing the Front Bezel” on page 41.
Step 3. Remove the front cover. See “Removing the Front Cover” on page 42.
