HP Integrity rx4640 User's & Service Guide

Appendix C
Utilities
Using the Boot Configuration Menu
193
For example:
Select the Console Output Device(s)
Acpi(PNP0501,0)/Uart(9600 N81)/VenMsg(PcAnsi)
Acpi(PNP0501,0)/Uart(9600 N81)/VenMsg(Vt100)
* Acpi(PNP0501,0)/Uart(9600 N81)/VenMsg(Vt100+)
Acpi(PNP0501,0)/Uart(9600 N81)/VenMsg(VtUtf8)
Acpi(HWP0002,700)/Pci(1|1)/Uart(9600 N81)/VenMsg(PcAnsi)
Acpi(HWP0002,700)/Pci(1|1)/Uart(9600 N81)/VenMsg(Vt100)
* Acpi(HWP0002,700)/Pci(1|1)/Uart(9600 N81)/VenMsg(Vt100+)
Acpi(HWP0002,700)/Pci(1|1)/Uart(9600 N81)/VenMsg(VtUtf8)
* Acpi(HWP0002,700)/Pci(2|0)
* indicates a currently selected device.
This menu is identical to Console Error Devices. The HP Integrity rx4640 server does not support different
configurations for Output and Error console. For correct operation:
• When changes are made to either Output or Error console menus, the identical change must be made in
both menus.
• When changing serial devices, changes must be made to Output, Input, and Error menus for proper
operation.
• Each option is identified with an EFI device path. Not all options will be available, depending on the
configuration of the server and the options purchased. Device paths may differ slightly on different
product models.
• On both serial device examples, UART 9600 indicates the current baud rate of the serial device (can be
changed with the EFI shell baud command), VenMsg Vt100+ is the current emulation type (several
different terminal emulation protocols are supported, see list above).
• Only one terminal emulation type (PcAnsi, Vt100, etc.) can be selected for each serial console, but
multiple serial consoles can be selected at a time.
Using the System Configuration Menu
The System Configuration Menu (on servers with EFI firmware version 2.0 or higher) includes the following
options:
• Advanced System Information
•Set System Time
•Set System Date
• Set User Interface
•Set System Wake-On LAN
•Set System Defaults
Table C-6 Console Output Devices
To select: Choose:
Serial A/Serial 1 Acpi(PNP0501,0)/Uart(9600 N81)/VenMsg(Vt100+)
iLO MP Serial Console Acpi(HWP0002,700)/Pci(1|1)/Uart(9600 N81)/VenMsg(Vt100+)
iLO MP VGA Port Acpi(HWP0002,700)/Pci(2|0)
