5. Remove two screws and the sheet metal bracket.
Figure 1-199 Remove the LVPS (4 of 10)
6. Remove the main fan. See Main fan on page 118.
7. Disconnect eight connectors and two FFCs from the DC controller.
NOTE: To locate DC controller connector locations, see DC controller connections on page 7.
Figure 1-200 Remove the LVPS (5 of 10)
ENWW
Removal and replacement procedures
133
