HP M525

Table 2-20 Numerical parts list (continued)
Part number Description Table and page
RM1-6279-000CN Cassette,Tray 3/4
500-sheet input tray (Tray 3
and Tray 4) on page 199
RM1-6301-000CN Paper delivery roller assembly
Internal assemblies (6 of 6)
on page 197
RM1-6303-000CN Separation holder assembly
Internal assemblies (3 of 6)
on page 191
RM1-6303-000CN Separation holder assembly
500-sheet input tray (Tray 3
and Tray 4) on page 199
RM1-6306-000CN Base plate roller assembly
Internal assemblies (3 of 6)
on page 191
RM1-6306-000CN Base plate roller assembly
500-sheet input tray (Tray 3
and Tray 4) on page 199
RM1-6311-000CN Face-down roller assembly
Internal assemblies (6 of 6)
on page 197
RM1-6315-000CN Transfer lower guide assembly
Internal assemblies (3 of 6)
on page 191
RM1-6321-000CN Roller, transfer
Internal assemblies (3 of 6)
on page 191
RM1-6322-000CN Laser/scanner
Internal assemblies (1 of 6)
on page 187
RM1-6323-000CN Tray pickup roller assembly
Internal assemblies (5 of 6)
on page 195
RM1-6325-000CN Multipurpose lifting plate assembly
Covers on page 177
RM1-6598-000CN Pendulum service kit
Internal assemblies (4 of 6)
on page 193
RM1-8498-000CN Cover, right assembly
Covers on page 177
RM1-8499-000CN Interlock switch assembly
Internal assemblies (5 of 6)
on page 195
RM1-8502-000CN Door, cartridge assembly
Covers on page 177
RM1-8505-000CN Tray 2, paper pickup assembly
Internal assemblies (5 of 6)
on page 195
RM1-8506-000CN Idler roller assembly
Internal assemblies (5 of 6)
on page 195
RM1-8507-000CN Registration roller assembly
Internal assemblies (3 of 6)
on page 191
RM1-8508-000CN Fuser assembly (universal)
Internal assemblies (5 of 6)
on page 195
RM1-8512-000CN Cassette, Tray 2
Internal assemblies (3 of 6)
on page 191
206 Chapter 2 Parts and diagrams ENWW
