Connectors, LED Indicators, Switches, and Jumpers
Compaq ProLiant DL380 Generation 2 Maintenance and Service Guide 4-17
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 12:45 PM
Table 4-9: System LEDs and Internal Health LED Status Combinations continued
System LED and Color Internal Health
LED Color
Status
Red
• Interleaving error: DIMM is missing from
the bank, and no valid memory exists in
another bank.
• Interleaving error: DIMMs are mismatched
within the bank, and no valid memory
exists in another bank.
DIMM failure, all slots in
one bank (Amber)
Amber
• DIMMs have failed over to the online
spare bank.
• Interleaving error: DIMM is missing from
the bank, but valid memory exists in
another bank.
• Interleaving error: DIMMs are mismatched
within the bank, but valid memory exists in
another bank.
DIMM failure, all slots in all
banks (Amber)
Red No valid or usable memory is installed in the
system.
Overtemperature (Amber) Red
• System has reached the operating system
cautionary level.
• System has exceeded the hardware
critical level.
Riser/SCSI interlock
failure (Amber)
Red PCI riser or Smart Array 5i Controller is
unseated. *
Power converter module
(Amber)
Red The power converter module has failed.
Red A primary fan has failed at least one zone. Fan (Amber)
Amber A redundant fan has failed at least one zone.
Note: * When the SCSI interlock disable switch is set to default (off), the riser/SCSI interlock failure
LED indicates that the PCI riser or the Smart Array 5i Controller is unseated. If the default setting is
changed for troubleshooting purposes (on), the LED indicates that only the PCI riser is unseated.
