Removal and Replacement Procedures
2-12 Compaq ProLiant DL380 Generation2 Server Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 1:12 PM
Universal Hot-Plug Tape Drive
To remove a universal hot-plug tape drive:
1. Press the release button on the hot-plug tape drive
 .
2. Pull the tape drive out of the bay
 .
1
2
Figure 2-7: Removing a universal hot-plug tape drive
CAUTION: Always populate the tape drive bay with either a tape drive or hard drive blank
and tape drive blank. Operating the server without installing a tape drive or blanks results in
improper airflow and improper cooling that can lead to thermal damage.
To replace the tape drive, slide the drive into the bay until it locks into place.

HP ProLiant DL380 - G2 Server Specifications

General

Form Factor	2U Rackmount
CPU	Intel Pentium III or Xeon
Storage	Up to 6 hot-plug SCSI drives
Network Controller	Integrated 10/100TX Ethernet
Power Supply	Dual redundant hot-plug
Expansion Slots	6 PCI (4x 64-bit, 2x 32-bit)
