Removal and Replacement Procedures
2-10 Compaq ProLiant DL380 Generation2 Server Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 1:12 PM
Hard Drive Blank
To remove a hard drive blank:
1. Press the release button
 .
2. Pull the blank out of the drive bay
 .
2
1
Figure 2-5: Removing a hard drive blank
CAUTION: Always populate hard drive bays with either a hard drive or hard drive blank.
Operating the server without installing a hard drive or hard drive blank results in improper
airflow and improper cooling that can lead to thermal damage.
To replace the hard drive blank, slide the blank into the bay until it locks into place.

HP ProLiant DL380 - G2 Server Specifications

General

Form Factor	2U Rackmount
CPU	Intel Pentium III or Xeon
Storage	Up to 6 hot-plug SCSI drives
Network Controller	Integrated 10/100TX Ethernet
Power Supply	Dual redundant hot-plug
Expansion Slots	6 PCI (4x 64-bit, 2x 32-bit)
