Illustrated Parts Catalog
1-4 Compaq ProLiant DL380 Generation 2 Server Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 12:45 PM
Table 1-2: System Components Spare Parts List continued
Item Description Part Number Spare Part
Number
13 Heatsink and heatsink clip 228075-001 228497-001
14 Air baffle 228073-001 228525-001
Boards
15 Processor power module (PPM), 12-V, 28.5-A 217336-001 228506-001
16 Smart Array 5i Controller 011003-003 228510-001
17 System board, with heatsink 010933-001 228494-001
18 Power converter module 207066-001 228505-001
19 SCSI backplane, 6-bay 010936-001 228502-001
20 CD MultiBay adapter board 010984-001 228504-001
21 Power button/LED board 010963-001 228503-001
Mass Storage Devices
22 Diskette drive, slimline, 1.44-MB 235168-001 228507-001
23 CD-ROM drive, IDE, 24X 222837-001 228508-001
23A DVD-ROM drive, 8X* 168003-935 —
Cables
24 SCSI cable kit * — 228517-001
SCSI cable, short, 68-pin 199606-018 —
SCSI cable, long, 68-pin 166298-035 —
25 Signal cable kit * — 228518-001
Power button/LED cable, 14-pin 219048-001 —
CD MultiBay cable, 50-pin 314014-006 —
PCI Hot Plug backplane cable 219049-001 —
26 Miscellaneous cable kit * — 228519-001
System cable (LED/CD-ROM drive or
diskette drive), 50-pin
219047-001 —
Remote Insight Lights-Out Edition interface
cable, 16- to 30-pin
233763-001 —
Rack-mounting Hardware
27 Rack-mounting hardware kit * — 232793-001
Standard rack rail, slide assembly, left 232041-001 —
Standard rack rail, slide assembly, right 232040-001 —
Cable management arm, assembly 227026-001 —
Note: * Not shown
