Removal and Replacement Procedures
Compaq ProLiant DL380 Generation2 Server Maintenance and Service Guide 2-17
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 1:12 PM
4. Slide the access panel toward the rear of the unit about 1.25 cm (0.5 inch) and lift to
remove the panel.
Figure 2-12: Removing the access panel
Reverse steps 1 through 4 to replace the access panel.
