Removal and Replacement Procedures
Compaq ProLiant DL380 Generation2 Server Maintenance and Service Guide 2-33
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 1:12 PM
9. Use a Torx T-15 screwdriver to remove the ejector assembly screw
.
10. Press and hold the ejection button.
11. Slide the ejector assembly toward the rear of the chassis and lift
.
1
2
Figure 2-28: Removing the CD ejector assembly
Reverse steps 1 through 11 to replace the CD ejector assembly.
