Removal and Replacement Procedures
2-42 Compaq ProLiant DL380 Generation2 Server Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 1:12 PM
8. From the rear of the PCI riser cage, press the slot release lever to unseat it
.
9. Rotate the slot release lever out of the chassis
.
1
2
Figure 2-37: Removing the PCI slot release lever
Reverse steps 1 through 9 to replace the PCI slot release lever.
