HP ProLiant DL380 - G2 Server User Manual

Removal and Replacement Procedures
2-46 Compaq ProLiant DL380 Generation2 Server Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 1:12 PM
8. Loosen the thumbscrew that secures the power converter module to the chassis  .
9. Slide and lift the power converter module off the chassis
 .
1
2
Figure 2-41: Removing the power converter module
from the chassis (cables removed for clarity)
Reverse steps 1 through 9 to replace the power converter module.

HP ProLiant DL380 - G2 Server Specifications

General

Form Factor	2U Rackmount
CPU	Intel Pentium III or Xeon
Storage	Up to 6 hot-plug SCSI drives
Network Controller	Integrated 10/100TX Ethernet
Power Supply	Dual redundant hot-plug
Expansion Slots	6 PCI (4x 64-bit, 2x 32-bit)
