Connectors, LED Indicators, Switches, and Jumpers
Compaq ProLiant DL380 Generation 2 Maintenance and Service Guide 4-7
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 12:45 PM
Table 4-4: Hot-Plug SCSI Hard Drive LED Status Combinations
Activity
(1)
Online
(2)
Fault
(3)
Means
On Off Off
Do not remove the drive. Removing a drive during this
process causes data loss.
The drive is being accessed and is not configured as part
of an array.
On Flashing Off
Do not remove the drive. Removing a drive during this
process causes data loss.
The drive is rebuilding or undergoing capacity expansion.
Flashing Flashing Flashing
Do not remove the drive. Removing a drive during this
process causes data loss.
The drive is part of an array being selected by the Array
Configuration Utility.
-Or-
The Options ROMPaq is upgrading the drive.
Off Off Off OK to replace the drive online if a predictive failure alert is
received (see the following section for details) and the drive
is attached to an array controller.
The drive is not configured as part of an array.
-Or-
If this drive is part of an array, then a powered-on controller
is not accessing the drive.
-Or-
The drive is configured as an online spare.
Off Off On OK to replace the drive online.
The drive has failed and has been placed off-line.
Off On Off OK to replace the drive online if a predictive failure alert is
received (see the following section for details), provided
that the array is configured for fault tolerance and all other
drives in the array are online.
The drive is online and configured as part of an array.
On or
flashing
On Off OK to replace the drive online if a predictive failure alert is
received (see the following section for details), provided
that the array is configured for fault tolerance and all other
drives in the array are online.
The drive is online and being accessed.
