Log Interval : 5
VPN-Instance Name and ID : vpnb, 2
Interfaces : Ethernet2/0/0
Address family ipv4
Create date : 2009/01/21 11:31:18
Up time : 0 days, 00 hours, 04 minutes and 36 seconds
Route Distinguisher : 100:2
Export VPN Targets : 222:2
Import VPN Targets : 222:2
Label Policy : label per route
The diffserv-mode Information is : uniform
The ttl-mode Information is : pipe
Log Interval : 5
[PE1] ping -vpn-instance vpna 10.1.1.1
PING 10.1.1.1: 56 data bytes, press CTRL_C to break
Reply from 10.1.1.1: bytes=56 Sequence=1 ttl=255 time=56 ms
Reply from 10.1.1.1: bytes=56 Sequence=2 ttl=255 time=4 ms
Reply from 10.1.1.1: bytes=56 Sequence=3 ttl=255 time=4 ms
Reply from 10.1.1.1: bytes=56 Sequence=4 ttl=255 time=52 ms
Reply from 10.1.1.1: bytes=56 Sequence=5 ttl=255 time=3 ms
--- 10.1.1.1 ping statistics ---
5 packet(s) transmitted
5 packet(s) received
0.00% packet loss
round-trip min/avg/max = 3/23/56 ms
Step 5 Establish the EBGP peer relationship between the PE and the CE to import VPN routes.
# Configure CE1.
[CE1] bgp 65410
[CE1-bgp] peer 10.1.1.2 as-number 100
[CE1-bgp] import-route direct
NOTE
The configuration procedures of CE2, CE3 and CE4 are similar to that of CE1.
# Configure PE1.
[PE1] bgp 100
[PE1-bgp] ipv4-family vpn-instance vpna
[PE1-bgp-vpna] peer 10.1.1.1 as-number 65410
[PE1-bgp-vpna] import-route direct
[PE1-bgp-vpna] quit
[PE1-bgp] ipv4-family vpn-instance vpnb
[PE1-bgp-vpnb] peer 10.2.1.1 as-number 65420
[PE1-bgp-vpnb] import-route direct
[PE1-bgp-vpnb] quit
NOTE
The configuration of PE2 is similar to that of PE1, and the details for the configuration procedure are not
provided here.
After the configuration, run the display bgp vpnv4 all peer command on the PE. You can see
that the BGP peer relationship is set up between the PE and the CE, and the peer status is
Established.
Use the peer relationship between PE1 and CE1 as an example.
[PE1] display bgp vpnv4 vpn-instance vpna peer
BGP local router ID : 1.1.1.9
Local AS number : 100
VPN-Instance vpna, router ID 1.1.1.9:
Total number of peers : 1 Peers in established state : 1
Peer V AS MsgRcvd MsgSent OutQ Up/Down State PrefRcv
10.1.1.1 4 65410 11 9 0 00:06:37 Established 1
