2.2.1 Establishing the Configuration Task

Applicable Environment

To connect a CE to multiple VPNs and isolate services of these VPNs, you need to configure

MCE functions. Before configuring MCE functions, you need to configure VPN instances on

an MCE and a PE.

Pre-configuration Tasks

Before configuring a VPN instance, complete the following tasks:

l Creating a VLAN on the MCE and adding the interface connecting the site and PE to the

VLAN

l Creating a VLAN on the PE and adding the sub-interface connecting the MCE to the VLAN

l Creating a VLAN on the device connected to the MCE in a site and adding the interface

connected to the MCE on the device to the VLAN

Data Preparation

To configure a VPN instance, you need the following data.

No.

Data

1 Name of the VPN instance

2 Route Distinguisher (RD) of the VPN instance

3 (Optional) Description of the VPN instance

4 (Optional) Maximum number of routes supported by the VPN instance

5 ID of the VLAN corresponding to the VPN instance

2.2.2 Creating a VPN instance

Context

Do as follows on the MCE.

You need to perform similar configurations on the PE; however, configuration commands and

methods may be different because device manufacturers and types are different. For details, refer

to manuals of corresponding products.

Procedure

Step 1 Run the system-view command to enter the system view.

Step 2 Run the ip vpn-instance vpn-instance-name command to create a VPN instance and enter the

VPN instance view.

Huawei AR1200 Series Enterprise Routers

Configuration Guide - VPN 2 MCE Configuration

Issue 01 (2012-04-20) Huawei Proprietary and Confidential
