Huawei AR1200 Series Configuration Guide

Context
NOTE
For more information about AAA, refer to the Huawei AR1200 Series Enterprise Routers Configuration
Guide - Security.
Do as follows on LNS:
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
l2tp-group group-number
The L2TP group view is displayed.
Step 3 Choose one of the following commands to configure the authentication scheme.
l Run the mandatory-lcp command to configure the mandatory LCP re-negotiation.
l Run the mandatory-chap to configure the mandatory local CHAP authentication.
l Skip this step to perform the agent authentication.
By default, the agent authentication is adopted.
Step 4 Run:
quit
Return to the system view.
Step 5 Run:
aaa
The AAA view is displayed.
Step 6 Choose one of the following commands to configure the user authentication.
l Run the local-user user-name password password command to configure the user name and
password if the local authentication is adopted.
l For the mandatory local CHAP authentication, LCP re-negotiation, and agent authentication,
the user name and password for authentication must be set on LNS.
l If the RADIUS authentication is adopted, see 4.3.5 (Optional) Configuring RADIUS
Authentication on LAC Side.
The user name and password configured on LNS must be consistent with those configured on
LAC.
By default, the local authentication is adopted.
----End
4.4.4 Allocating Addresses to Access Users
Users belong to different domains. The users whose domains are not specified belong to the
default domain. After an L2TP tunnel is set up between an LAC and an LNS, the LNS selects
Huawei AR1200 Series Enterprise Routers
Configuration Guide - VPN 4 L2TP Configuration
Issue 01 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
261
