9. RouterA transmits the parameters of the CHAP response, response identifier and PPP
negotiation to RouterB.
10. RouterB sends an access request to the LNS RADIUS server for authentication.
11. The LNS RADIUS server authenticates this access request and replies with a response if
the authentication is successful.
12. If the local mandatory CHAP authentication is configured on RouterB, RouterB
authenticates the user by sending a CHAP challenge. The user replies with a CHAP
response.
13. RouterB resends this access request to the LNS RADIUS server for authentication;
14. The LNS RADIUS server re-authenticates this access request and replies with a response
if the authentication is successful.
15. After authentication is complete, the user can access the enterprise resources.
4.2 Configuring Basic L2TP Functions
In L2TP configurations, you need to configure basic L2TP functions before configuring other
L2TP functions.
4.2.1 Establishing the Configuration Task
Before configuring basic L2TP functions, familiarize yourself with the applicable environment,
complete the pre-configuration tasks, and obtain the required data. This can help you complete
the configuration task quickly and accurately.
Applicable Environment
The L2TP group is an important concept that you need to know when configuring L2TP. After
configuring an L2TP group, you can flexibly configure L2TP functions on the device and realize
point-to-point or point-to-multipoint networking applications between the L2TP Access
Concentrator (LAC) and the L2TP Network Server (LNS).
Pre-configuration Tasks
None
Data Preparation
To configure basic L2TP functions, you need the following data.
No.
Data
1 Number of the L2TP group
2 Names of the tunnels on the LAC side and the LNS side
Huawei AR1200 Series Enterprise Routers
Configuration Guide - VPN 4 L2TP Configuration
Issue 01 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
250
