Address DIP
Switch 1
DIP
Switch 2
DIP
Switch 3
DIP
Switch 4
DIP
Switch 5
DIP
Switch 6
4 OFF OFF ON OFF OFF OFF
5 ON OFF ON OFF OFF OFF
6 OFF ON ON OFF OFF OFF
7 ON ON ON OFF OFF OFF
8 OFF OFF OFF ON OFF OFF
9 ON OFF OFF ON OFF OFF
10 OFF ON OFF ON OFF OFF
11 ON ON OFF ON OFF OFF
12 OFF OFF ON ON OFF OFF
... ... ... ... ... ... ...
48 OFF OFF OFF OFF ON ON
The DIP switch of a cabinet electronic clasp lock should be set to the reverse of the binary
value of the corresponding address. Examples based on the preceding table:
If the address of a cabinet electronic clasp lock is 4, set its DIP switch to 001 as the binary
value of 4 is 100. That is, set switches 1 and 2 to OFF and set switch 3 to ON.
If the address of a cabinet electronic clasp lock is 8, set its DIP switch to 0001 as the binary
value of 8 is 1000. That is, set switches 1, 2, and 3 to OFF and set switch 4 to ON.
If the address of a cabinet electronic clasp lock is 12, set its DIP switch to 0011 as the
binary value of 12 is 1100. That is, set switches 1 and 2 to OFF and set switches 3 and 4 to
ON.
If the address of a cabinet electronic clasp lock is 16, set its DIP switch to 00001 as the
binary value of 16 is 10000. That is, set switches 1, 2, 3, and 4 to OFF and set switch 5 to
ON.
If the address of a cabinet electronic clasp lock is 48, set its DIP switch to 000011 as the
binary value of 48 is 110000. That is, set switches 1, 2, 3, and 4 to OFF and set switches 5
and 6 to ON.
Step 4 Add a cabinet electronic clasp lock.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Create a cabinet view in Smart Module View on the home page.
3. Add a cabinet electronic clasp lock.
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 204
