Huawei FusionModule2000-S User Manual

Table 5-28 Adding a cabinet electronic clasp lock
Path Parameter
Name
Setting
Choose System Settings
> Device Management
and click Add Device.
The parameters for
adding devices are
displayed.
Device
Attribute
Cabinet electronic clasp lock
Device Type Cabinet electronic clasp lock
Connect To ECC800-Pro
Communicat
ions Port
Odd-numbered cabinets: COM2
Even-numbered cabinets: COM3
Device
Address
Enter the actual device address of
the cabinet electronic clasp lock.
4. Click Test Connect to check whether the connection between the cabinet
electronic clasp lock and the ECC800-Pro is normal.
– If the connection is normal, click
Conrm. The connected devices are
displayed in the Number of connected devices list.
– If the connection is abnormal, check whether the device is properly
connected to the ECC800-Pro, whether the device and the ECC800-Pro are
running properly, and whether the parameter settings are consistent with
the device parameters.
5. Repeat Step 4.3 and Step 4.4 to connect other cabinet electronic clasp locks.
6. Click Unhide All Advanced Signals, then click Power Supply Parameters.
Ensure that I power supply enable(AIDI_2/COM1/AIDI_4/COM3) and II
power supply enable(AIDI_3/COM2/AIDI_5) are Enable.
Step 5 Commission the cabinet electronic clasp locks.
Table 5-29 Function commissioning
Function
Path Operation
View
cabinet
electroni
c clasp
lock
informati
on
Choose
Monitoring >
Cabinet > IT
Cabinet101 >
E-LOCK1a.
Click the
Running Info
tab.
View the running information
about cabinet electronic clasp
lock 1 on the WebUI.
Change
a cabinet
electroni
c clasp
lock
name
Click the
Running
Parameters tab.
Change the cabinet electronic
clasp lock name.
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 205
