Figure 5-59 ONVIF parameters
7. Remove the network cable from the PC to the PoE port on the ETH gateway.
8. Connect the PC to the LAN1 port on the ECC800-Pro using a network cable,
and reconnect the network cable between the smart ETH gateway and the
LAN2 port on the ECC800-Pro.
Step 2 Set the IP address for the C3220 camera.
1. Enter https://192.168.248.10 in the address box of the browser and press
Enter to access the WebUI login page. After login, choose System Settings >
Video Management.
2. (Optional) Click Search.
– The search timeout interval is 10s. If the search fails, a search failure message is
displayed.
– To avoid missing cameras, you can perform Search for multiple times.
3. On the found camera record, click
and set the external IP address and
related parameters for the camera based on the one allocated by the network
administrator (PC IP address and camera external IP address should be in the
same network segment).
4. Click the link under Link to access and log in to the camera WebUI. Enter the
preset user name admin and the preset password HuaWei123, and click Log
In.
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 225
