2. Click Edit in the row where the value of Parameter Name is SDKNatIP and
set Value to the NAT-mapped IP address congured on the rewall. Click
Save.
3. Click Edit in the row where the value of Parameter Name is SDKNatPort and
set Value to the NAT mapped port number congured on the rewall. Click
Save.
(4) Set other parameters based on the site requirements by referring to the
preceding steps.
Table 5-39 Parameter description
Module
Name
Parameter
Name
Setting
IMGU IMGUNNatIP Northbound IP address of the IVS1800, which
must be the same as the NAT-mapped IP
address congured on the rewall.
IMGUNNatPo
rt
NAT port number of the IVS1800 IMGU, which
must be the same as the NAT-mapped port
number congured on the rewall.
The default port number of the IMGU before
mapping is 9554.
MU MUNNatIP Northbound IP address of the IVS1800, which
must be the same as the NAT-mapped IP
address congured on the rewall.
NatRtspServer
Port
NAT port number of the IVS1800 MU, which
must be the same as the NAT mapped port
number congured on the rewall.
The default port number of the MU before
mapping is 554.
NatRtspTlsSer
verPort
TLS NAT port number of the IVS1800 MU,
which must be the same as the NAT mapped
port number congured on the rewall.
The default TLS port number of the MU before
mapping is 322.
Step 7 (Optional) Congure the IVS1800 to synchronize time with the NTP server. Choose
Local
Conguration > Server conguration and congure the server time
information.
