Item Specications
LAN port ● Supports two LAN ports, which can be connected to the
LAN. The ports support autonegotiation of 10/100/1000
Mbit/s communication rates.
● Connect shielded network cables to the LAN ports.
RS485 serial
port
expansion
● Output voltage: 13–15 V DC (rated voltage: 14.5 V DC)
● Four RS485 ports with the default communications rate of
9600 bit/s
● COM1–COM3 ports provide 12 V DC power.
● The power supply can be switched on or o and is on by
default.
PoE expansion Supports two PoE (GE) ports for expansion of the PoE bus, and
supports network isolation and ring network.
AIDI
expansion
(RJ45)
● Output voltage: 13–15 V DC (rated voltage: 14.5 V DC)
● Provides ve universal AIDI ports for connecting to sensors
such as smoke sensors, water sensors, and NTC sensors.
AIDI_1 to AIDI_3 are full-function AIDI ports, and AIDI_4 to
AIDI_5 are simplied AIDI ports without type identication.
● The power supply can be switched on or o and is on by
default.
DO expansion
(RJ45)
● Output voltage: 13–15 V DC (rated voltage: 14.5 V DC)
● Supports one active DO port.
● The power supply can be switched on or o and is on by
default.
Fault isolation There are three groups of 12 V ports. A group has a maximum
current of 660 mA, a route has a maximum current of 800 mA,
and the maximum total current is 2 A.
Group 1: 12 V of the AIDI_1 and DO/12V ports
Group 2: 12 V of the AIDI_2, COM1/AIDI_4, and COM3/12V
ports
Group 3: 12 V of the AIDI_3 and COM2/AIDI_5 ports
Wireless
communicatio
n
Supports wireless communication that complies with
IEEE802.15.4.
FusionModule500 Smart Mini Data Center
User Manual 3 System Architecture
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 33
