Huawei FusionModule800 User Manual

Check Item Specications Check Result
Floor drain DN50 or larger, made of cast iron or
stainless steel
□ Passed □ Failed
Grounding A general ground bar is congured in
the Converged Cabinet. The general
ground point in each cabinet connects
to the general ground bar in the
Converged Cabinet. The general ground
bar in the Converged Cabinet connects
to the
oor ground bar or collective
ground bar.
□ Passed □ Failed
Water port Condensate drain outlet: for draining
condensate from the smart cooling
product.
□ Passed □ Failed
Humidier water pipe port: Connects to
external water pipes to supply water to
the humidier.
□ Passed □ Failed
NO TE
If any of the requirements is not met, contact Huawei technical support.
NO TICE
The UPS can generate large leakage currents. A circuit breaker equipped with an
RCD is not recommended. If leakage protection is required, select a recommended
upstream circuit breaker for the smart module.
Table 4-4 Recommended circuit breaker (NetCol500)
Load
Recommende
d Cable and
Circuit
Breaker
Specication
s
One Cooling
Only Smart
Cooling
Product
Terminal
Specication
s
Earth
Leakage
Circuit
Breaker
≤ 8.5 kW Circuit
breaker
specications
MCB D63/3P - 100 mA
Input power
cable
specications
5 x 8 AWG
10 mm
2
cord
end terminal
-
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 96
