3.2.2 Working Principles
Conceptual Diagram for the N Power Distribution System
Figure 3-10 Conceptual diagram for the N power distribution system
3.2.3 Key Hardware Devices
3.2.3.1 Power Distribution Module
Table 3-4 Power distribution module specications
Item
Specications
System parameters Single input, IT load power ≤ 8.5 kW, two 6 kVA UPSs,
one smart cooling product; front operation, front and
rear maintenance
Dimensions (H x W x
D)
130.5mm×442mm×450mm
FusionModule800 Smart Small Data Center
User Manual 3 System Architecture
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 28
