Figure 4-41 Concrete base requirements
4.2.6.3.2 Space Requirements
Single Outdoor Unit
● A single outdoor is recommended to be installed against a wall, as shown in
Figure 4-42.
Figure 4-42 Space requirements for installing single outdoor unit
If the outdoor unit cannot be installed against a wall or the local outdoor
temperature may be below –10°C (NetCol500-A018) or 0°C (NetCol500-A020)
or –10°C (NetCol500-A021), place an air
bae at the air intake side of the
outdoor unit based on the Figure 4-43.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 127
