Step 3 Remove the gas spring.
Figure 6-2 Removing a gas spring
Step 4 Tighten the new air spring using an adjustable wrench.
----End
6.4.1.3 Replacing a PDU2000
Prerequisites
● Tools: Phillips screwdriver, step ladder
● Material: A spare PDU2000 of the same model is available and functional.
Context
A PDU2000 is installed at the rear door of a cabinet.
Procedure
Step 1 Open the rear door of the cabinet.
Step 2 Switch o the output circuit breaker of the power distribution subrack for the
PDU2000. Disconnect the power cables and signal cables from the PDU2000
terminal block.
Step 3 Remove the bolts that secure the PDU2000 using a Phillips screwdriver.
Step 4 Secure the new PDU2000 to the rear door of the cabinet.
Step 5 Reconnect the power cables or signal cables to the PDU2000, and switch on the
circuit breaker of the power distribution subrack.
----End
FusionModule800 Smart Small Data Center
User Manual 6 O&M
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 400
