Application
Scenario
Specications Remarks
Naked crimping terminal: OT, 6 mm
2
,
M6, 50 A, tin plating, 12-10 AWG,
yellow
Delivered with the
ttings
Signal cable to
the indoor and
outdoor units
(optional)
Electrical power cable, 300 V, SJTW,
16-22 AWG, black (three core wires:
black, white, green), 10 A, shielded
outdoor cable, UL
The length is
determined by site
survey.
Naked crimping terminal, single-wire
cord end terminal, 1.5 mm
2
, 7.5 A, tin
plating, insertion depth 12 mm, black
Delivered with the
ttings
Naked crimping terminal: OT, 1.5 mm
2
,
M4, 18 A, tin plating, 22-16 AWG, red
Delivered with the
ttings
4.2.6.2 Layout Principles
The layout principles are as follows:
● If the outdoor unit is placed higher than the indoor unit, the maximum height
deviation between them should be less than or equal to 30 meters. Install an
oil trap every 5–6 meters in the vertical direction along the gas pipe.
● If the indoor unit is placed higher than the outdoor unit, the maximum height
deviation between them should be less than or equal to 8 meters.
NO TICE
● The height deviation refers to the distance from the stop valves of the indoor
unit to the stop valves of the outdoor unit.
● is a sign of a tilt, and it indicates that the scale of the pipe tilting is 1:200.
The pipe tilting direction should be consistent with the hypotenuse of the right
triangle.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 124
