Figure 3-41 Smoke detector
Table 3-46 Smoke detector technical specications
Item Specications
Operating voltage 9–27 V
Alarm current < 20 mA
Indication Monitoring: The red indicator blinks
once every 3 to 8 seconds.
Alarm reporting: The red indicator is
steady on.
Operating temperature –10°C to +55°C
Ambient humidity ≤ 95% RH
Dimensions (H x W x D) 31 mm x 75 mm x 51 mm (with the
base)
Weight 50 g
3.4.3.9 Cabinet Electronic Clasp Lock
The cabinet electronic clasp lock is used to manage access control. It can be
automatically unlocked, or manually locked and unlocked.
FusionModule800 Smart Small Data Center
User Manual 3 System Architecture
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 71
