4.2.1.1 Cabinet Transportation and Unpacking
Context
● Only trained personnel are allowed to move the cabinet. Remove the packed
cabinet from the pallet using a pallet truck and move the cabinet to the
installation position.
● To prevent the cabinet from falling over, secure it to the pallet truck using
ropes before moving it.
● To prevent shocks or falls, move the cabinet gently. After placing the cabinet
in the installation position, unpack it and take care to prevent scratches. Keep
the cabinet steady during unpacking.
● If the cabinet installation environment is in poor condition, to well store the
cabinet after it is unpacked, take measures to prevent dust. You can wrap the
cabinet with the original plastic coat.
Do not tear down the transparent lm from the glass door during the installation.
The lm will be removed after the entire module is installed.
Procedure
Step 1 Use a pallet truck to transport the cabinet to the installation position.
Step 2 Check that the cabinet package is intact.
Step 3 Cut
o and remove the binding straps, and remove the packing.
Step 4 Remove the pallet from a common cabinet (IT cabinet and network cabinet).
1. Remove the plastic bag and take out the
tting box.
2. Check the cabinet exterior for damage. If any damage is found, notify the
carrier immediately.
3. Check against the packing list that the equipment and
ttings are correct and
complete. If some
ttings are missing or do not comply with the packing list,
record the information and contact your local Huawei oce immediately.
4. After checking that the cabinet is intact, remove the screw assemblies that
secure the cabinet to the pallet, as shown in Figure 4-7.
Set the screw assemblies aside for they will be used in installation steps.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 101
