● Before installing the access actuator, ensure that the clip spring on the back of
the actuator is loose.
● Verify that the access actuator indicator faces leftwards so that the indicator
status can be observed through the window in the waterproof box cover after
the waterproof box cover is reinstalled.
Figure 4-156 Installing an access actuator
Step 6 Reinstall the waterproof box cover.
Figure 4-157 Reinstalling the waterproof box cover
----End
4.2.9.12 (Optional) Installing an In-Room Double Door Magnetic Lock?
Prerequisites
● Verify that the room door is a revolving double-swing wooden door, and that
the door frame is wider than 42 mm.
● The cable routes are planned.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 202
