Huawei FusionModule800 User Manual

Table 5-11 Adding a T/H sensor
Path Parameter Setting
Choose
System
Settings >
Device
Management
and click Add
Device. The
parameters
for adding
devices are
displayed.
Device
attribute
Select Sensor from the drop-down list box.
Device type Select T/H sensor from the drop-down list
box.
Connect to Select ECC800 from the drop-down list box.
Communica
tions port
Select COM1 from the drop-down list box.
NOTE
The setting example indicates that the T/H sensor
is connected to the COM1 port on the ECC800-
Pro. If the T/H sensor is connected to another
port, enter the number of the connected port.
Device
address
In this example, Device address is set to 1.
During actual conguration, set the device
address for the T/H sensor based on the
actual situation.
3. Click Connect Test to check whether the T/H sensor connects to the ECC800-
Pro properly.
– If the connection is normal, click
Conrm. The connected devices are
displayed in the Number of connected devices list.
– If the connection is abnormal, check whether the device is properly
connected to the ECC800-Pro, whether the device and the ECC800-Pro are
running properly, and whether the parameter settings are consistent with
the device parameters.
Step 3 Check functions of the T/H sensor.
Table 5-12 Function check
Check Method
Normal Connection Status
Check the running
information about the T/H
sensor on the WebUI.
Choose Monitoring > Aisle > T/H Sensor Group
> T/H Sensor n > Running Info, and check the
current T/H and NTC information of the cabinet.
Set T/H sensor alarm
thresholds.
Choose Monitoring > Aisle > T/H Sensor Group
> T/H Sensor n > Running Parameters, and set
High temperature alarm threshold, Low
temperature alarm threshold, High humidity
alarm threshold, Low humidity alarm
threshold, NTC1–6 high temperature alarm
threshold and NTC1–6 low temperature alarm
threshold as required.
FusionModule800 Smart Small Data Center
User Manual 5 Power-On Commissioning
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 280
