Figure 5-41 Setting audio and video parameters
If longer-time video storage is required, set camera parameters according to the following table.
Table 5-26 Camera conguration parameters
Condition
Result
Encoding
Protocol
Resolution Frame
Rate
I-Frame
Interval
Minimum
Bit Rate
Required
Supported
Video
Storage
Duration
(h)
H.265 1080P 25 50 1 Mbit/s 66
H.264 1080P 25 50 1 Mbit/s 66
H.265 720P 25 50 0.8 Mbit/s 75
H.264 720P 25 50 1 Mbit/s 66
H.265 720P 25 50 0.6 Mbit/s 105
H.264 720P 25 50 0.8 Mbit/s 75
Step 4 Choose Settings > Intelligent Analysis > Common Intelligence. Select Enable,
click Add, add motion detection areas, set motion detection parameters, and click
Save.
FusionModule800 Smart Small Data Center
User Manual 5 Power-On Commissioning
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 312
