Huawei FusionModule800 User Manual

Table 3-38 Description of the eLight strip light colors
Scenario Light Color Remarks
Non-associated
alarm severity
Blue
NOTE
On the ECC800-Pro WebUI, set
Associated Alarm Severity to None.
-
Associated alarm
severity
Mapping between smart module
alarm severities and strip light
colors:
● Critical: red
● Major: orange
● Minor: yellow
● Warning: white
● No alarm: strip light
o
Critical and major
alarms are
associated by
default. Alarms of
any severity can be
associated manually.
Alarms are
associated with the
eLight on both ends.
If associated alarms
at multiple severities
appear, the strip light
color indicates only
the highest alarm
severity.
eLight fault The eLight disconnects from the
ECC800-Pro and blinks in red.
-
Table 3-39 eLight technical specications
Item
Specications
eLight power supply ● Rated input voltage: 220/230/240 V AC
● Frequency: 50/60 Hz
● Output: ≥ 93 W, 24 V DC
● Certication: CE
eLight actuator ● Rated input voltage: 24 V DC
● Two output channels. The I output is connected to
the RGBW exible strip light, and supplies dierent
voltages depending on host instructions so that the
light can be in dierent colors. The II output
supplies a
xed voltage of 24 V DC.
● Modbus communications protocol, RS485 port, two
RJ45 ports
●
Certication: CE
FusionModule800 Smart Small Data Center
User Manual 3 System Architecture
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 65
