N2000H V3 Appliance
User Guide
1 Product Overview
Issue 04 (2018-11-06)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
Silk Screen
Meaning
Color
State Description
button for 6 seconds to power off
the Appliance.
UID
button/indicator
Blue
The UID button/indicator
helps identify and locate a
Appliance in a rack. You can
turn on or off the UID
indicator by manually
pressing the UID button or
remotely running a command
on the iBMC CLI.

Steady on: The Appliance
is located.

Off: The Appliance is not
located.

You can hold down the
UID button for 4 to 6
seconds to reset iBMC.
Health indicator
Red and
green

Steady green: The
Appliance is operating
properly.

Blinking red at 1 Hz: A
major alarm is generated.

Blinking red at 5 Hz: A
critical alarm is generated.
-
Hard disk active
indicator
Green

Off: The hard disk is not
detected or is faulty.

Blinking green: Data is
being read from, written to
the hard disk, or
synchronized between hard
disks.

Steady green: The hard
disk is inactive.
-
Hard disk fault
indicator
Yellow

Off: The hard disk is
operating properly or hard
disks cannot be detected in
the RAID group.

Blinking yellow: The hard
disk is being located, or
the RAID is being
reconstructed.

Steady yellow: The hard
disk is not detected or is
faulty.
