Huawei N2000H V3 User Manual

N2000H V3 Appliance
User Guide
1 Product Overview
Issue 04 (2018-11-06)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
26
Component
Specifications
Network port

Four GE optical ports, supporting NC-SI, WOL, and PXE
PCIe slot

The N2000H V3 provides one PCIe 3.0 x8 slot for the RAID
controller card and 2 standard PCIe 3.0 x8 slots.
The specifications for the five standard PCIe slots are described as
follows:
− Two half-height half-length standard PCIe 3.0 x8 slots on the
mainboard (PCIe slot signals come from CPU 1.)

PCIe slots on an I/O module can house a maximum of two Huawei
ES3000 V2 SSDs to improve I/O performance for search, cache, and
download services.
NOTE

Specifications of I/O module 1:

Two 3.5-inch hard disk slots
Port

Two USB 2.0 ports

Two USB 3.0 ports, one DB15 VGA port, one DB9 serial port, and
one RJ45 system management port on the rear panel

One internal USB 3.0 port and two Mini SSD (SATADOM) ports
Fan module
Four hot-swappable fan modules, tolerating the failure of a single fan.
PSU
Two hot-swappable PSUs are in redundancy mode:

750 W AC Platinum PSU, supporting 240 V HV DC
System
management

UEFI

HUAWEI iBMC: supports Intelligent Platform Management
Interface (IPMI), Serial over LAN (SOL), KVM over IP, and virtual
media, and provides one 10/100/1000M RJ-45 management network
port.

NCSI
Security

Power-on password

Administrator password

Chassis cover opening logging

Front bezel
1.12 Technical Specifications
This topic describes the technical specifications for the N2000H V3.
Table 1-10 describes the technical specifications for the N2000H V3.
Table 1-10 Environmental specifications
Item
Specifications
